The surface of metal parts worked through turning, reaming or boring operations is a succession of “PROJECTION or PEAKS” and “INDENTATION or VALLEY” when microscopically examined (see fig. 1). The roller Burnishing Operation compresses the “Projection (Peaks)’ into the “Indentation” (Valleys) thus forming a smooth mirror finished surface (as in fig. 2). Any material not exceeding 40 Rockwell Hardness “C” can be rolled bumished.
Interiors of Hydraulic oil brake cylindersInternal surface and taper seat surface of valve bodiesInternal surface of bushings for connecting roadHoles for inserting bearingsInternal surface of gun barrelsInternal surface of brass liners for torque convertersValve seats of fuel pumpsExternal surface tapers for jointsSpherical seat surface of oil jointsSubmersibles Buss & All type of Gears| Tool Dia (mm) |
Speed (rpm) |
Tool Feed Rate (mm / rev) |
|---|---|---|
| 10 – 15 | 610 – 3100 | 0.45 – 0.90 |
| 15 – 20 | 500 – 1800 | 0.75 – 0.90 |
| 20 – 25 | 380 – 1500 | 0.8 – 1.4 |
| 25 – 30 | 320 – 1010 | 1.3 – 1.7 |
| 30 – 35 | 275 – 875 | 1.5 – 2.1 |
| 35 – 40 | 230 – 850 | 2.0 – 2.5 |
| 40 – 45 | 210 – 690 | 2.1 – 2.6 |
| 45 – 50 | 195 – 615 | 2.9 – 3.1 |
| 50 – 55 | 175 – 535 | 3.5 – 4.0 |
| 55 – 60 | 165 – 515 | 3.9 – 4.3 |
| 60 – 65 | 145 – 465 | 4.3 – 4.6 |
| 65 – 70 | 150 – 440 | 2.3 – 2.6 |
| 70 – 75 | 120 – 405 | 2.6 – 2.7 |
| 75 – 90 | 115 – 385 | 2.7 – 2.4 |
| 90 – 100 | 100 – 320 | 3.3 – 4.0 |
| 100 – 115 | 90 – 290 | 4.0 – 4.5 |
| 115 – 130 | 80 – 230 | 5.0 – 5.4 |
| 130 – 140 | 70 – 215 | 5.8 – 6.0 |
